Versatile Axle Weighing System

Rice Lake’s AX3040 is a versatile axle weighing system providing accurate vehicle weights in non-Legal for Trade applications.

The AX3040 axle scale system includes two diamond tread platforms with on/off ramps. The tandem platforms can weigh a total of 60,000 pounds or 80,000 pounds (30,000 pounds or 40,000 pounds per platform). Combined with the TuffSeal® signal trim junction box and EL147HE cable, the AX3040 axle scale system is the ideal solution for onsite non-Legal for Trade vehicle weighing.

Axle Scale Platform Choice - Length and Material

The AX3040 axle scale is available in your choice of length—7, 12 or 14 feet - and is available in aluminum or mild steel. Depending on the size, some vehicles can capture total weight in one step instead of weighing individual axles. The AX3040 axle scale system has a low profile for gradual ramp incline while maintaining durabilityand consistent weighments.

Scales

• Sizes: 7 ft, 12 ft and 14 ft lengths
• Construction: Steel or aluminum
• Axle capacity, tandem platforms: 60,000 or 80,000 lb (30,000 or 40,000 lb each)
• Includes (4) 5/8-11 NC eye bolts for lifting scale during installation
• Contains two load cells per platform
• Treaded top plate with four lifting eyes
• JB4SS TuffSeal® signal trim junction box
• 10 ft EL146HE Interconnect cable with MS-type connectors to go between weigh pads
• 50 ft EL147HE cable to connect weigh pad to indicator
• Non-Legal for Trade

• Ramps: (L × W) 7 ft and 12 ft scales: 5.63 × 32.00 in, 14 ft scale: 5.75 × 32.00 in
• Steel or aluminum
• Anchor bolts not included
