Standard Features
• Heavy-duty industrial design
• Structural steel channel frame
• Four NTEP Certified alloy steel, shear beam load cells
• 20 ft SURVIVOR® EL147HE hostile environment load cell cable
• TuffSeal® JB4SS stainless steel, NEMA Type 4X junction box with signal trim card
• Side-access junction box
• Rugged diamond deck safety treadplate
• 4 adjustable stainless steel SUREFOOT™ support feet
• 4 corner overload stops (Canadian versions only)
• Level bubble (Canadian versions only)

Specifications
End Load Capacity: 200% full scale at 1,000 lb, 100% full scale at 2,000 lb and 5,000 lb, 80% full scale at 10,000 lb
Cable Length: 20 ft (6.1 m) for connecting junction box to indicator
Threaded Eyebolt: Hole (1/2-20 NF) located in center of deck for easy lifting
Warranty (limited): RoughDeck HP weldment five years, load cells two years, all other components one year
Approvals: NTEP CC 92-001, Class III 5,000d, Measurement Canada AM-4827, Class III 5,000d

Base Only - Indicator and calibration available separately.
