We are proud to present the Rice Lake SCT-1100 Advanced Series Signal Conditioning Weight Transmitter. You can use this transmitter as a low cost solution with any application where weight data is required such as PLC, remote display or PC.

• Up to four independent scales or four load cell inputs


• Quick menu for real and theoretical calibration


• Red LED display (13 mm) and six LEDs show active functions


• Standard DIN rail-mounting with power supply and enclosures


• Configurable calibration and setup parameters from keyboard


• Up to three calibration linearization points or three from the keyboard


• Reading of the net, gross and tare weights, clearing, semi-automatic and presettable tare, scale switch, setting of outputs application thresholds


• Diagnostic information via serial port, message display, printing, setting of APW in counting mode, simulation of key pressure

The ideal solution for PLC systems which require weight data from a scale, Rice Lake’s SCT signal transmitters offer maximum control without the additional cost or space required of a traditional weight indicator.

These multi-function transmitters have a compact design while presenting the same signal-conditioning functions.

Utilized as an independent or dependent four-channel digital junction box, the SCT-1100 allows for the direct reading and diagnosis of each individual connected load cell or summed as a whole.

INDICATOR ONLY, base sold separately.

Order Now or call a Digital Indicator Specialist at 877-65-SCALE !
