MSI-9300 138705 Port-A-Weigh Plus Crane Scale w/CellScale™ RF - 2,000 lb Final Assembly
MSI-9300 138705 Port-A-Weigh Plus Crane Scale w/CellScale™ RF - 2,000 lb Final Assembly
SKU:138705
Regular price
$7,170.00 USD
Regular price
$7,170.00 USD
Sale price
$7,170.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
The Premier Solution for Wireless Overhead Weighing and Process Control Applications
The MSI-9300 crane scale combines an integrated weight display with advanced wireless data processing capability providing versatile solutions in overhead industrial weighing applications. The MSI-9300 merges MSI’s advanced CellScale® technology with world-renowned crane scale designs providing local and remote control capabilities along with connectivity with plant information systems.
This model features industrial-grade, shock-mounted electronics, watertight packaging with large ultra-bright displays readable at distances up to 50 feet (15m). Integrated CellScale® technology offers the ability to effectively monitor and control single or multiple crane scales from multiple locations throughout plant operations. Wireless, real-time transmission of weight and product information can be processed through a system-configured network of CellScale® components from distances up to 1,000 feet (300m) with standard antennas. Operating range can be further increased with optional antennas configured with other networked CellScale® components.
Both fixed and handheld digital weight indicators are available in addition to RF modems for wireless connectivity with peripheral computers and scoreboards. Optional 802.11b/g Ethernet connectivity is also supported for adaptation and integration with existing plant information systems.
The MSI-9300 is available in a standard range of capacities, up to 50 tons. Larger and application specific designs are available for capacities over 50 tons. Additional options and configurations are also available for mill and foundry over high temperature ladle installations.
The MSI-9300 crane scale combines an integrated weight display with advanced wireless data processing capability providing versatile solutions in overhead industrial weighing applications. The MSI-9300 merges MSI’s advanced CellScale® technology with world-renowned crane scale designs providing local and remote control capabilities along with connectivity with plant information systems.
This model features industrial-grade, shock-mounted electronics, watertight packaging with large ultra-bright displays readable at distances up to 50 feet (15m). Integrated CellScale® technology offers the ability to effectively monitor and control single or multiple crane scales from multiple locations throughout plant operations. Wireless, real-time transmission of weight and product information can be processed through a system-configured network of CellScale® components from distances up to 1,000 feet (300m) with standard antennas. Operating range can be further increased with optional antennas configured with other networked CellScale® components.
Both fixed and handheld digital weight indicators are available in addition to RF modems for wireless connectivity with peripheral computers and scoreboards. Optional 802.11b/g Ethernet connectivity is also supported for adaptation and integration with existing plant information systems.
The MSI-9300 is available in a standard range of capacities, up to 50 tons. Larger and application specific designs are available for capacities over 50 tons. Additional options and configurations are also available for mill and foundry over high temperature ladle installations.
- Crane unit with 2.4 GHz Spread Spectrum transceiver
- Six-digit, 1.2 in (30 mm) LED display and annunciators
- Top lifting eye or shackle, bottom thrust bearing swivel hook
- 12 volt rechargeable battery and universal 115/230 VAC, 50/60 Hz battery charger (NA Plug Standard)
Order Now or Call an Industrial Scale Specialist Toll Free at 877-65-SCALE !
Brochures
msi-9000-cell-scale-rf-wireless-weighing-solutions-specs msi-overhead-weighing-msi-product-guide
Downloads
| Description Tag | MSI-9300 138705 Port-A-Weigh Plus Crane Scale w/CellScale™ RF - 2,000 lb Final Assembly |
|---|---|
| ID | 7261 |
| Width | 0 |
| Depth | 0 |
| Height | 0 |
| Price | 7170 |
| Cost Price | 0 |
| Retail Price | 0 |
| Sale Price | 0 |
| Tax Class ID | 0 |
| Brand ID | 177 |
| Condition | New |
| View Count | 144 |
| SKU | 138705 |
| Custom Product | false |
| Capacity-1 | 2000lb |
| UDF Name 1 | ENCLOSURE |
| UDF Name 2 | FUNCTIONS |
| UDF Name 3 | DISPLAY |
| UDF Value 1 | NEMA Type 4, IP66, marine grade 356 alloy anodized cast aluminum |
| UDF Value 2 | POWER, ZERO, NET/GROSS, TARE and Programmable TEST/USER |
| UDF Value 3 | Six digit, 1.2 in (30 mm) LED with 14 feature annunciators and programmable brightness control |
| Cart Price | 5557.5000 |
| Sensitivity-1 | 1lb |
| Amazon Brand | RICE LAKE |
| Options Capacity | 2000 x 1lb |
| Brand Google | RICE LAKE WEIGHING SYSTEMS |
| Ship Length | 24.0000 |
| Ship Width | 24.0000 |
| Ship Height | 15.0000 |
| CAPACITY | 2000lb |
| Sensitivity | 1lb |
| UDF Name 1 | ENCLOSURE |
| UDF Name 2 | FUNCTIONS |
| UDF Name 3 | DISPLAY |
| UDF Value 1 | NEMA Type 4, IP66, marine grade 356 alloy anodized cast aluminum |
| UDF Value 2 | Power, zero, net/gross, tare and programmable test/user |
| UDF Value 3 | Six digit, 1.2 in (30 mm) LED with 14 feature annunciators and programmable brightness control |
| Cart Price | 5557.5000 |
| Amazon Brand | RICE LAKE |
| Available Options | 2000 x 1lb |
| Brand | RICE LAKE WEIGHING SYSTEMS |
| Dimension Length | 24.0000 |
| Dimension Width | 24.0000 |
| Dimension Height | 15.0000 |
